16mm Coil by Disorderly Conduction

This is the whip and heating coil for use with all models of the PeliNail electric nail. The heater coils feature a 5-foot long Kevlar encased cord, various coil sizes, and a standard 5-pin XLR connector.

Features:

• 5-pin XLR connector
• Length: 5 ft. Kevlar sheathed cord
• Resistance Material: Ni80Cr20 from Germany
• One-Year Warranty on Coil through Disorderly Conduction

• 120V 100W
• Also compatible with analog and digital D-Nail units, EzBake Enail, ShatterBox Enail and some other 5-pin XLR units (Please double check how your XLR port is wired with the diagram below)
• DC 25mm Kevlar Coil is compatible with XL Toro Grail, Highly Educated The Gavel , XL Eternal Quartz, XL Ionic Quartz, Joel Halen Flat Tops


*WARNING* WHEN USING ANY SIZE COIL WITH QUARTZ PLEASE TAKE COIL OFF THE NAIL BEFORE THE NAIL COOLS TO AVOID CHANCE OF DAMAGING YOUR QUARTZ


**DC KEVLAR COILS DO NOT WORK WITH: HIGH5VAPE PRODUCTS, CASA COIL or DABBERBOX**


Diagram for how XLR is wired on DC Coils

Pin1, Pin2 are power for coil;
Pin3, TC+;
Pin4, TC-;
Pin5, Ground;

This Information can be used for someone looking to use the DC Kevlar Coil with a DIY XLR port they or someone else built, but cannot be guaranteed on non-PeliNail products. If the XLR port is not wired the same way as above the Coil will not heat up and might cause damage to unit or coil.
